Model No：KFL5025
Measure：50*50*25 mm
Feature：
．Housing: enviromental protection and fireproof PBT（UL94V-0）.
．Impeller: enviromental protection and fireproof PBT（UL94V-0）.
．Enameled copper wire: B class insulation,withstand high temperature 155℃.
．Bearing: high-precision,long-life and low noise ball bearing.
．Motor: Impedance protection.
Operating temperature：
ball bearing:-30℃ to + 75℃ 30%-85% RH
sleeve bearing:-10℃ to + 70℃ 30%-85% RH
Specification :
Model No. | Voltage | Operating Voltage | Current | Power | Speed | Air Flow | Static Pressure | Noise | ||
V | V | A | W | RPM | M³/Min | CFM | mmH2O | inH2O | dB-A | |
KFL502505L | 5 | 3.6~6.8 | 0.16 | 0.80 | 3000 | 0.087 | 3.090 | 5.222 | 0.599 | 35 |
KFL502512L | 12 | 6.0~13.5 | 0.11 | 1.32 | ||||||
KFL502505M | 5 | 3.6~6.8 | 0.21 | 1.05 | 3500 | 0.105 | 3.727 | 7.623 | 0.301 | 38 |
KFL502512M | 12 | 6.0~13.5 | 0.14 | 1.68 | ||||||
KFL502524M | 24 | 18~26.5 | 0.08 | 1.92 | ||||||
KFL502505H | 5 | 3.6~6.8 | 0.35 | 1.75 | 4000 | 0.113 | 3.993 | 11.240 | 0.442 | 40 |
KFL502512H | 12 | 6.0~13.5 | 0.20 | 2.40 | ||||||
KFL502524H | 24 | 18~26.5 | 0.10 | 2.40 | ||||||
KFL502512H-HH | 12 | 6.0~13.5 | 0.25 | 3.00 | 5000 | 0.151 | 5.305 | 20.801 | 0.819 | 46 |
KFL502524H-HH | 24 | 18~26.5 | 0.12 | 2.88 | ||||||
 |  |
